MET-01 Dilator Anti-deformation and Strength Tester
MET-01 Dilator Anti-deformation and Strength Tester is used to determine the deflection and strength of various disposable sterile vaginal dilators.
Technical Features
Ø Meet the function test of the vaginal dilators anti-deformation ability and structural strength
Ø 7-inch color touch screen with intelligent data processing function
Ø High-performance motor module and drive system to ensure the stability of data during the test
Ø Imported load cell with high precision and strong stability
Ø Adopt high-precision displacement sensor to accurately measure deflection value
Ø Various parameters can be set and test results can be printed
Ø Automatic calibration and calibration
Ø With automatic data storage and power-off automatic memory function
Ø With a powerful data storage function, which can store up to 100,000 test records.
Security protection
Ø The software has an over-range shutdown function to effectively protect the sensor safety
Data Security
Ø Equipped with four-level user security password policy to ensure the security of test data
Ø The computer software fully complies with the GMP "Computerized System" requirements and has functions such as user management, authority management, and data audit tracking. (optional)
Applications
Basic Applications | Sterile Vaginal Dilator for Single Use |
Extended Applications | Puncture, Pressure Resistance test |
Technical Specifications
Specifications | MET-01 |
Test Range | 0~ 500N |
Test Accuracy | ± 0.5% FS |
Deflection | 0.01mm ~ 50mm |
Error Range | 0.02mm |
Resolution | 0.001N |
Stroke | 300mm |
Test Speed | 0 ~ 600mm/min |
Instrument Dimension | 400mm (L) x 460mm(W) x 770mm(H) |
Power Supply | AC 220V 50Hz/ AC 110V 60Hz |
Net Weight | 33.5Kg |
Standards
YY0336
Configuration
Standard configuration: Instrument, micro printer, touch screen, test fixture.
