HRT-05 Medical Device Flow Rate Tester
HRT-05 Medical Device Flow Rate Tester adopts the positive pressure test principle and is designed in accordance with ISO 7864, YY0821, GB 8368, GB 15811, and GB15812.1. HRT-05 is used to test the flow rate, pressure resistance and sealing reliability by applying water pressure to the test sample and maintaining it for a certain period of time.
Technical Features
Ø 7-inch HD color touch screen, displays test data and curve in real-time
Ø Equipped with a liquid storage buffer tank to stabilize pressure and provide a hydraulic environment
Ø Equipped with a liquid buffer reservoir to stabilize the pressure and provide a hydraulic environment
Ø With luer connection, can test a variety of needles, catheters
Ø Safety designs such as overvoltage protection and power-off memory ensure system stability
Ø The machine detects the pressure changes every 0.1s and maintains the set pressure automatically, effectively controls the pressure fluctuation within the acceptable range
Ø Equipped with standard RS232 interface, which is convenient to PC connection and data transmission
Originality Design
Ø Adopts high-precision electronic flow controller to realize precise control of gas flow
Ø Pressure and time can be preset, input the value directly to enter the test mode
Ø With a powerful data storage function, storing up to 100,000 test records
Ø The result is determined automatically, the test data can be printed
Applications
Basic Applications | Syringe Needle | Patency and flow rate test |
Infusion Needle | Patency and flow rate test |
Catheter | Flow rate test |
Technical Specifications
Specifications | HRT-05 |
Test Range | 0 ~ 600kPa |
Test Accuracy | 0.1% FS |
Liquid Reservoir | Acrylic |
Connector | Luer connector |
No. of Load Cell | 1 |
Instrument Dimension | Instrument: 310mm (L) ×370mm (W) ×150mm (H) Liquid Reservoir: 220 (L) x220 (W)x250 (H) |
Power Supply | AC 220V 50Hz/ AC 110V 60Hz |
Net Weight | 30Kg |
Standards ISO 7864, YY0821, GB 8368, GB 15811, GB15812.1
Configuration
Standard configuration: Instrument, 7-inch touch screen, liquid reservoir and micro printer.
Note: 1.The gas supply port of the instrument is Φ8 mm PU Tubing;
2. Customers will need to prepare for gas supply.
