DVT-03 Infusion Sets Leakage Tester (negative pressure)
DVT-03 Infusion Sets Leakage Tester is suitable for negative pressure leakage test of infusion sets. It can also be used for negative pressure leakage test of various catheters such as blood transfusion sets and anesthesia filters.
Product Features
Ø 0~ -90Kpa wide negative pressure test range for various catheters
Ø Equipped with vacuum transition tank to prevent water from backing up into the equipment
Ø High-speed and high-precision sampling chip to ensure test accuracy and effectiveness
Ø Automatic constant pressure air supplement to ensure that the test can be carried out under preset vacuum conditions
Ø Automatic blowback and unloading function, making the end of the test process simple and smooth
Ø Safety design such as over-voltage safety protection and power-down memory ensure the stability of the system during the test
Ø Equipped with standard RS232 interface, which is convenient to PC connection and data transmission
Originality design
Ø 7” HD LCD, displaying test data in real time
Ø Gradient test mode easy to find out the critical value of specimen leakage pressure
Ø Vacuum degree and time can be preset, input the value can enter the test mode
Ø With a powerful data storage function, which can store up to 100,000 test records
Ø The result is automatically determined, and the test data can be printed
Ø The results are automatically determined and the test data can be printed
Ø Supports historical data for quick viewing and printing
Safety protection
Ø With shutdown function for pressure over-range, which protects the sensor.
Data security
Ø Equipped with a four-level user security password policy to ensure the security of test data
Ø The computer software fully complies with the requirements of GMP "Computerized System" and has functions such as user management, authority management, and data audit tracking.
Technical Specifications
Specifications | DVT-01 |
Test Range | 0 ~ -90kPa |
Accuracy | 0.5%FS |
Vacuum Maintain Performance | Automatic pressure maintain |
Test Time | 0～99999s (Setting freely) |
Test Error | ≤ ± 1 |
Power Supply | 220V, 50Hz |
Net Weight | 20Kg |
Applications
Basic Application | Extended Application |
Infusion sets | Blood transfusion sets |
Catheters | Anesthesia filter |
Standards
ISO8536-4, EN1618, GB 15812.1, GB8368
Configuration
Standard Configuration: Instrument, 7-inch touch screen, liquid storage tank, micro printer.
