LEAK-02H Positive & Negative Pressure Tester
LEAK-02H Positive & Negative Pressure Tester adopts positive and negative dual pressure test principle, and tests the leakage of the test sample by applying positive or negative pressure. It is suitable for the sealing test of various pipeline products such as infusion sets, syringes, sterile catheters, etc. in the medical device industry.
Technical Features
Ø Positive and negative pressure dual test principle, precise pressure test system, greatly improved test accuracy
Ø Built-in four test modes
Ø Standard test connector, and optional customized one
Ø Overvoltage safety protection, power-off memory and other safety designs ensure system stability
Ø Equipped with standard RS232 interface, which is convenient to PC connection and data transmission
Originality design
Ø 7” HD LCD, displaying test data in real time
Ø Pressure and time can be preset, input the value directly to enter the test mode
Ø With a powerful data storage function, which can store up to 100,000 test records
Ø The results are automatically determined and the test data can be printed
Ø Supports quick viewing and printing of historical data
Safety protection
Ø With shutdown function for pressure over-range, which protects the sensor.
Data security
Ø Equipped with a four-level user security password policy to ensure the security of test data
Ø The computer software fully complies with the requirements of GMP "Computerized System" and has functions such as user management, authority management, and data audit tracking.
Technical Specifications
Specifications | LEAK-02H |
Pressure Range | Positive pressure: 0～600kPa; Negative pressure: 0～ -90kPa |
Accuracy of Vacuum Degree | 0.1%FS |
Test Time | 0 ～ 9999min |
Test Mode | Positive pressure, Negative pressure, Positive pressure to negative pressure, Negative pressure to positive pressure. |
Gas Supply Pressure | 0.7~0.9MPa (Not in supply scope) |
Port of Gas Supply | Φ6 mm PU Tubing |
Dimension | Instrument: 310mm(L)×385mm(W)×150mm(H) |
Power Supply | AC 220V 50Hz/ AC 110V 60Hz |
Net Weight | 17Kg |
Configuration
Standard configuration: Instrument, 7-inch touch screen, standard connector, positive & negative pressure chamber and micro printer.
Note: 1.The gas supply port of the instrument is Φ6 mm PU Tubing;
2. Customers will need to prepare for gas supply.
