HRT-04 Infusion Sets Leakage Tester (positive pressure)
HRT-04 Infusion Sets Leakage Tester is suitable for positive pressure leakage test of infusion sets. It can also be used for positive pressure leakage test of various catheters such as blood transfusion sets and anesthesia filters.
Technical Features
Ø Embedded micro-computer chips, simplified and efficient user interface provide users with comfortable and smooth operating experience
Ø Safety designs such as overvoltage protection and power-off memory ensure system stability
Ø Equipped with standard RS232 interface, which is convenient to PC connection and data transmission
Ø Pressure and time can be preset, input the value directly to enter the test mode
Originality design
Ø 7” HD LCD, displaying test data in real time
Ø Gradient test mode easy to find out the critical value of specimen leakage pressure
Ø With a powerful data storage function, which can store up to 100,000 test records
Ø The result is automatically determined, and the test data can be printed
Ø The results are automatically determined and the test data can be printed
Ø Supports historical data for quick viewing and printing
Safety protection
Ø With shutdown function for pressure over-range, which protects the sensor.
Data security
Ø Equipped with a four-level user security password policy to ensure the security of test data
Ø The computer software fully complies with the requirements of GMP "Computerized System" and has functions such as user management, authority management, and data audit tracking.
Applications
Basic Application | Extended Application |
Infusion sets | Blood transfusion sets |
Catheters | Anesthesia filter |
Technical Specifications
Specifications | HRT-04 |
Test Range | 0～600kPa; 0～87psi (standard) |
0～1.6 MPa; 0～232.1 psi (optional) |
Accuracy of Pressure Sensor | ≤ 3‰ |
Resolution | 0.1kpa |
Gas Supply Pressure | 0.4~0.7MPa (Not in supply scope) |
Port of Gas Supply | Φ8 mm PU Tubing |
Dimension | Instrument: 310mm(L)×370mm(W)×150mm(H) Liquid Reservoir: 215mm(L)×215mm(W)×240mm(H) |
Power Supply | AC 220V 50Hz/ AC 110V 60Hz |
Net Weight | 25Kg |
Standards ISO8536-4, EN1618, GB8368, GB 15812.1
Configuration
Standard configuration: Instrument, 7-inch touch screen, liquid reservoir and micro printer.
Note: 1.The gas supply port of the instrument is Φ8 mm PU Tubing;
2. Customers will need to prepare for gas supply.
